Auroria

Veloria² Plus

Powerful and lightweight

Article No. 0985

The Veloria² suction unit is a high-quality suction unit for professional foot care. Be surprised by the very quiet powerful suction. Milling dust is picked up directly at the milling cutter and reliably separated in the fine dust filter.

The handpiece is equipped with our patented clamping system with soft button. Thanks to the ergonomic shape, with a diameter of only 19 mm, even working in a pencil posture is comfortable.

The powerful brushless motor runs at a speed of 6,000 to 40,000 rpm. By means of foot switch (accessory) the
switched on and off.

Veloria² Plus / Highlights

Handpiece with Suction
Handpiece with Suction
Easy Filter Exchange
Easy Filter Exchange
Ultra-Silent High Performance Suction
Ultra-Silent High Performance Suction

Veloria² Plus / Details

Handpiece

features-auroria-handstueck-handschuh

A small handpiece diameter (17 mm) ensures for a comfortable posture. The ergonomic design of handpiece makes it the ideal solution for long fatigue-free working.

The knob of the Quick Chuck Device, which allows you to change the tools easily and securely, has been made of TPE (thermoplastic elastomer). TPE is a soft material that makes it comfortable to use the knob.

Power Clamping System

The handpiece is equipped with a unique, patented clamping system. A chuck will open inside the handpiece by pressing the well-known hadewe knob forward. The instrument can now be entered into the unit without any resistance. This is especially important with smaller, sharp edged tools, since they can cause injury, if you need too much force to enter an instrument.

Pushing the knob back again will close the chuck, and the tool will be held very secure, even at high speeds. The tight grip also ensures the low-vibration running of the hand piece for which hadewe is famous.

Conventional clamping systems with automatic clamping work with a mechanism in which rolls inside the handpiece wedge the instrument under pressure. At these systems it is not possible to enter the instrument without resistance.

The handpieces with automatic clamping are also more sensitive to small deviations of tool tolerances. This will lead to higher vibration and poor holding force. That’s why the power clamping system is superior in many ways.

The 3 support jaws can be opened manually. This allows entering of the tools without resistance. It also prevents the tool from accidentally slipping out.

features-auroria-handstueck-spannsystem

Ultra-Silent High Performance Suction

features-auroria-handstueck-motor

According to customer surveys a silent suction is one of the most important criteria to buy a podiatry drill. The motor itself, as well as the quality of sound damping are important factors. The use of different kinds of insulating material makes it possible to reduce a wide spectrum of noise. After all neither a high frequency squeaking nor a dull humming should disturb your treatment.

Regular suction turbines are working with so called brush motors. The brushes are grinding on the turning engine shaft, and this wears them down. This conventional technology has been successfully implemented a thousand times. However, it has the disadvantages of high brushes attrition as well as a larger and heavier construction. The suction turbine implemented in the newer hadewe models (for example Medeas, Auroria and Veloria) is based on a technology without brushes. This method is also used in modern computer ventilators for example. The advantage is less attrition and significantly less weight.

Filter Changing & Chuck Cleaning

As soon as the display shows that a filter change is required, you only need to open the hatch at the side of the unit to replace the filter with a new one. The filter chamber is easily accessed and can be comfortably opened thanks to the magnet holders in the door.

The filter bags are classified as class M filters by the BIA (Germany’s Health & Safety Institute for the work environment), meaning they have a dust retention capacity of 99,9%.

A simple and fast maintenance of the most basic components is one of the important qualities of the hadewe hand pieces. The chuck can be easily removed with the spanner tool delivered with every unit. Loosen the top of the hand piece, and then turn out the chuck. The whole procedure takes less than one minute.

features-auroria-filterwechsel

Quality Made in Germany

The quality of our products meets highest and latest requirements, since we know that only premium products can offer professional performance. For that reason we manufacture according to highest quality standard. All processes from development to production take place in our facilities in Hanover, and you receive the whole product from a single source. Short ways, quick decisions, optimal solutions and creation of value became our company philosophy. To the benefit of our customers.

Veloria² Plus / Technical Data

Unit
Article No.0985
Size in mm
(incl. exterior parts)
W 273 x H 142 x D 186
W 313 x H 142 x D 235
Suction MotorBrushless suction motor
Weight2,7 kg
Voltage230 V
Noise Level49 - 55 dB (A)
Foot SwitchOptional Foot Switch
Carry CasesSuitable for all hadewe carry cases
Handpiece
Speed6.000 rpm - 40.000 rpm
Length144 mm
Diameter19 - 25 mm
Clamping Systemhadewe Power Clamping
Handpiece MotorBrushless
Weight150 g
Instrument Shaft SizeØ 2,35 mm
